1 內(nèi)部連接器



1.1 主板連接器 (J9)



主板連接器是基于40柱連接器類型Atom Wafer 1.0mm雙排40pin或類似的

Note

Type

Signal

PIN

Signal

Type

Note



 PWR

 +3.3V

1

2

 GND

 PWR



 PWR

 +3.3V

3

4

 NC

 PWR

 GND

5

6

 NC

 USB2_TH_DP

7

8

 GND

 PWR

 USB2_TH_DP

9

10

 NC

 PWR

 GND

11

12

 NC

 PWR

 +5V

13

14

 GND

 PWR



 DP_HPD

15

16

 T1N

 Complement Signal Link Lane 1

 TOUCH_INT_EDP_N

17

18

 T1P

 True Signal Link Lane 1



 TOUCH_RST_EDP_N

19

20

 GND

 PWR



 I2C5_TCH_SCL_EDP

21

22

 T0P

 Complement Signal Lane 0

 I2C5_TCH_SDA_EDP

23

24

 T0N

 True Signal Link Lane 0

 PWR

 GND

25

26

 GND

 PWR

 PWR

 +3.3V

27

28

 AN_AUX_P

 True Signal Auxiliary Channel

 PWR

 GND

29

30

 AN_AUX_N

 Comp Signal Auxiliary Channel

 PWR

 GND

31

32

 GND

 PWR

 +VCC_EDP_BKLT

33

34

 NC



 +VCC_EDP_BKLT

35

36

 NC

 L_BKLT_CTRL

37

38

 GND

 PWR

 L_BKLT_EN_R

39

40

 GND

 PWR



注意 ： 可用的線材裝備







1.2 LVDS 平板連接器 (J8)

Lvds連接器是基于40柱連接器類型Atom Wafer 1.0mm雙排40pin或類似的

Note

Type

Signal

PIN

Signal

Type

Note



 PWR

 +5V

1

2

 LVDS_U3_P

 LVDS



 PWR

 +3.3V

3

4

 LVDS_U3_N

 LVDS

 BKL_EN

5

6

 LVDS_U2_P

 LVDS

 BKL_PWM

7

8

 LVDS_U2_N

 LVDS

 LVDS_DDC_CLK

9

10

 LVDS_U1_P

 LVDS



 LVDS_DDC_DATA

11

12

 LVDS_U1_N

 LVDS



 NC

13

14

 LVDS_U0_P

 LVDS



 NC

15

16

 LVDS_U0_N

 LVDS

 PWR

 GND

17

18

 LVD_UCLK_P

 LVDS

 LVDS_L3_P

19

20

 LVD_UCLK_ N

 LVDS

 LVDS_L3_N

21

22

 GND

 PWR



 LVDS

 LVDS_L2_P

23

24

 NC

 LVDS

 LVDS_L2_N

25

26

 TOUCH_INT_EDP_N

 LVDS

 LVDS_L1_P

27

28

 TOUCH_RST_EDP_N

 LVDS

 LVDS_L1_N

29

30

 I2C5_TCH_SCL_EDP

 LVDS

 LVDS_L0_P

31

32

 I2C5_TCH_SDA_EDP

 LVDS

 LVDS_L0_N

33

34

 GND

 PWR



 LVD_LCLK_P

35

36

 USB2_TH_DP

 LVD_LCLK_ N

37

38

 USB2_TH_DN

 PWR

 GND

39

40

 GND

 PWR

注意: 這個lvds接口支持單通道或者雙通道，spwg屏且*大支持1920x1080分辨率

Signal

Description

LVDS_L_TXn_P/N

LVDS 0 Channel data

LVDS_L_CLK_P/N

LVDS 0 Channel clock

LVDS_U_TXn_P/N

LVDS 1 Channel data

LVDS_U_CLK_P/N

LVDS 1 Channel clock

BKL_PWM

Backlight control (1), PWM signal to implement voltage in the range 0-3.3V

BKL_EN

Output Display Enable.

+5V

VCC supply to the display (1A Max.). Power sequencing depends on LVDS panel selection.
