參數說明：
• CPU: Intel® Atom™ D525
- Dual-core, 1.8GHz, 1M cache
• Chipset: Intel® ICH8M
內存規格
• 2G DDR3 1333MHz SODIMM sockets
• Supports up to 4GB memory
• Single channel memory interface
顯示方式
• Intel® GMA 3150
• Supports 2 independent displays
• VGA display resolution up to 2048x1536 @ 60Hz
• DVI display resolution up to 1366x768 @ 60Hz
• Display outputs: 1 VGA and 1 DVI (DVI-D signal)
存儲方式
• 2 2.5" SATA drive bays
- SATA 2.0 port with data transfer rate up to 3Gb/s
- Standard: 1 drive bay for 1 SATA drive
- Option: 1 drive bay for 2 SATA drives (Available upon request. Please
contact your sales representative for more information.)
• 1 CompactFlash socket
• Supports 1 mSATA module via the mini PCIe socket
網口
• 2 Realtek® RTL8111DL Gigabit Ethernet controllers
• 3 Intel® WG82574L PCI Express Gigabit Ethernet controllers
(EC200-LR4G65)
音效
• Realtek® ALC262 High Definition Audio
• 2 watt, 4Ω power amplifier
內擴展槽
• 1 Mini PCIe slot
電源
• Power input voltage: 19-24V DC (標準)
• Power input voltage: 9-36V DC (寬電壓選配)
環境
• 溫度
- Operating: 0oC ~+ 50oC (Standard Temperature)
- Operating: -20oC ~ +70oC (Wide Temperature)
- Storage: -20oC ~ 70oC
• 規范
- MIL-STD-810F 514-5C-2 (HDD)
• Operating Shock
- Half sine wave 15G, 11ms, 3 shock per axis
材質
• Aluminum + SECC
裝備方式
• Wall/VESA mount
尺寸大小
• 275mm x 55mm x 203mm (W x H x D)
重量
• 2.68 kg
系統支持
• Windows 7 Embedded, Windows 7, Windows XP SP3, Windows XP
Embedded, Linux
其他特性
• Watchdog Timer function
已過認證
• CE
• FCC Class A
• UL
• RoHS
