韓國LS產電K300S系列PLCGM4-PA2A
點擊圖片查看原圖
品牌： LS產電
品牌： LS
單價： 面議
所在地： 上海
有效期至： 長期有效
最后更新： 2024-06-09 17:17
瀏覽次數： 486
詢價
店鋪基本資料信息

 產品詳細說明
公司簡介
LS產電（原韓國LG集團）是韓國產業電器制造業的***，2005年正式更名為LS產電，是專業開發、生產、銷售低壓變頻器，中高壓變頻器，伺服驅動器，PLC，HMI，低壓電氣，中高壓開關等電力產品的高新科技企業。在韓國，LS產電株式會社的產品是韓國電器（氣）系統的產品，其中PLC、變頻器、電壓電器等市場占有率達到50%以上，是韓國電器（氣）的支柱企業

產品

QQ截圖20160709212829
QQ截圖20160709211253

QQ截圖20160709200042

產品參數

QQ截圖20160709212533

XGT（模塊型） 型號 說明

LS產電 CPU模塊 XGK-CPUH CPU Module(0.028μs), Max. I/O 6,144 points, Memory 64 ksteps
LS產電 CPU模塊 XGK-CPUS CPU Module(0.084μs), Max. I/O 3,072 points, Memory 32 ksteps
LS產電 CPU模塊 XGK-CPUE CPU Module
LS產電 CPU模塊 XGK-CPUA CPU Module
LS產電電源模塊 XGP-ACF1 Input Power Free Voltage, Output DC 5V:3A, DC 24V:0.6A
LS產電電源模塊 XGP-ACF2 Input Power Free Voltage, Output DC 5V:6A
LS產電電源模塊 XGP-AC23 Input Power AC 220V, Output DC 5V: 8.5 A
LS產電電源模塊 XGP-DC42 Input Power DC 24V, Output DC 5V:6A
LS產電 PLC基板 XGB-M04A Base board, 4 slots for I/O Module
LS產電 PLC基板 XGB-M06A Base board, 6 slots for I/O Module
LS產電 PLC基板 XGB-M08A Base board, 8 slots for I/O Module
LS產電 PLC基板 XGB-M12A Base board, 12 slots for I/O Module
LS產電擴展基板 XGB-E04A Base board(for Expansion), 4 slots for I/O Module
LS產電擴展基板 XGB-E06A Base board(for Expansion), 6 slots for I/O Module
LS產電擴展基板 XGB-E08A Base board(for Expansion), 8 slots for I/O Module
LS產電擴展基板 XGB-E12A Base board(for Expansion), 12 slots for I/O Module
LS產電擴展電纜 XGC-E041 Cable between Main and Expansion Base (0.4m)
LS產電擴展電纜 XGC-E061 Cable between Main and Expansion Base (0.6m)
LS產電擴展電纜 XGC-E121 Cable between Main and Expansion Base (1.2m)
LS產電擴展電纜 XGC-E301 Cable between Main and Expansion Base (3.0m)
LS產電擴展電纜 XGC-E501 Cable between Main and Expansion Base (5.0m)
LS產電擴展電纜 XGC-E102 Cable between Main and Expansion Base (10m)
LS產電擴展電纜 XGC-E152 Cable between Main and Expansion Base (15m)
LS產電擴展接頭 XGT-TERA Expansion Terminator(基板終端電組)
LS產電輸入模塊 XGI-D21A DC 24V Input 8 points, (Sink/Source)
LS產電輸入模塊 XGI-D22A DC 24V Input 16 points, (Sink/Source)
LS產電輸入模塊 XGI-D22B DC 24V Input 16 points, (Source)
LS產電輸入模塊 XGI-D24A DC 24V Input 32 points, (Sink/Source)
LS產電輸入模塊 XGI-D24B DC 24V Input 32 points, (Source)
LS產電輸入模塊 XGI-D28A DC 24V Input 64 points, (Sink/Source)
LS產電輸入模塊 XGI-D28B DC 24V Input 64 points, (Source)
LS產電輸入模塊 XGI-A12A AC 110V Input 16 points
LS產電輸入模塊 XGI-A21A AC Free Voltage Input 8 points
LS產電輸出模塊 XGQ-RY1A Relay Output 8 points
LS產電輸出模塊 XGQ-RY2A Relay Output 16 points
LS產電輸出模塊 XGQ-RY2B Relay Output 16 points(Surge Killer:Varister, CR Absorber)
LS產電輸出模塊 XGQ-TR2A Tr.(NPN Type) Output 16 points(DC12/24V 0.5 A)
LS產電輸出模塊 XGQ-TR2B Tr.(PNP Type) Output 16 points(DC12/24V 0.5 A)
LS產電輸出模塊 XGQ-TR4A Tr.(NPN Type) Output 32 points(DC12/24V 0.1A)
LS產電輸出模塊 XGQ-TR4B Tr.(PNP Type) Output 32 points(DC12/24V 0.1A)
LS產電輸出模塊 XGQ-TR8A Tr.(NPN Type) Output 64 points(DC12/24V 0.1A)
LS產電輸出模塊 XGQ-TR8B Tr.(PNP Type) Output 64 points(DC12/24V 0.1A)
LS產電輸出模塊 XGQ-SS2A SSR(Current Sink Type) Output 16 points(AC 110/220V 0.6A)
LS產電混合模塊 XGH-DT4A Hybrid I/O , DC24V Input 16 Points, Tr. Output 16Points
LS產電模擬量模塊 XGF-AV8A Analog Input 8 Channels, DC1~5V, 0~5V, DC0~10V, -10~10V
LS產電模擬量模塊 XGF-AC8A Analog Input 8 Channels, DC4~20mA, 0~20mA
LS產電模擬量模塊 XGF-AD4S Analog Input 4 Channels, DC1~5V,0~5V,0~10V,-10~10V,4~20mA,0~20mA
LS產電模擬量模塊 XGF-AD8A
LS產電模擬量模塊 XGF-DV4A Analog Output 4 Channels, DC1~5V, 0~5V, 0~10V, -10~+10V
LS產電模擬量模塊 XGF-DV8A
LS產電模擬量模塊 XGF-DV4S Analog Output 4 Channels, DC1~5V, 0~5V, 0~10V, -10~+10V(Insulation)
LS產電模擬量模塊 XGF-DC4A Analog Output 4 Channels, DC4~20mA, 0~20mA
LS產電模擬量模塊 XGF-DC08A
LS產電模擬量模塊 XGF-DC4S Analog Output 4 Channels, DC4~20mA, 0~20mA(Insulation)
LS產電特殊模塊 XGF-TC4S Thermocouple Input, 4 Channels(Type : K, J, E, T, B, R, S, N, C)
LS產電特殊模塊 XGF-RD4A Resistive Temperature Detectors, 4Channels (Pt100, Jpt100)
LS產電特殊模塊 XGF-RD4S Resistive Temperature Detectors, 4Channels (Pt100, Jpt100-Insulation)
LS產電特殊模塊 XGF-HO2A High Speed Count Module, 2 Channel 200kpps,Open Collector Type
LS產電特殊模塊 XGF-HD2A High Speed Count Module, 2 Channel 500kpps,Line Drive Type
LS產電特殊模塊 XGF-PO1A Position Module, 1 axis, Open Collector type Output
LS產電特殊模塊 XGF-PO2A Position Module, 2 axis, Open Collector type Output
LS產電特殊模塊 XGF-PO3A Position Module, 3 axis, Open Collector type Output
LS產電特殊模塊 XGF-PD1A Position Module, 1 axis, Line Drive type Output
LS產電特殊模塊 XGF-PD2A Position Module, 2 axis, Line Drive type Output
LS產電特殊模塊 XGF-PD3A Position Module, 3 axis, Line Drive type Output
LS產電特殊模塊 XGF-M16M Motion Control, Mechatrolink-Ⅱ 16-axis, speed 10Mbps)
LS產電通訊模塊 XGL-CH2A RS-232C/422 (Each 1 channel)
LS產電通訊模塊 XGL-C22A RS-232C 2 Channels
LS產電通訊模塊 XGL-C42A RS-422 2 Channels
LS產電通訊模塊 XGL-EFMF Fast Ethernet(Fenet, Optical Cable)
LS產電通訊模塊 XGL-EFMT Fast Ethernet(Fenet, Coaxial Cable)
LS產電通訊模塊 XGL-EDMF Fast Ethernet(FDEnet, Optical Cable)
LS產電通訊模塊 XGL-EDMT Fast Ethernet(FDEnet, Coaxial Cable)
LS產電通訊模塊 XGL-RMEA R-Net Master, 1Mbps
LS產電通訊模塊 XGL-DMEA Device Net (Speed Max.500Kbps / Distance: Max.500m)
LS產電通訊模塊 XGL-PMEA Profibus-DP (Speed Max. 12Mbps / Distance: 1,200m)
LS產電占空模塊 XGT-DMMA Dummy module for Empty I/O Slots
LS產電PLC軟件 XG5000 Program Editing & Engineering Software
LS產電PLC軟件 XG-PD Network Setting & Monitoring & Diagnosis Tool
LS產電PLC軟件 APM Package Positioning Parameter/Data Setting & Monitoring Tool
LS產電人機界面(HMI) 說明

LS產電觸摸屏 PLC,XP80-TTA/AC TFT 256 Color Touch Screen, 12.1"
LS產電觸摸屏 PLC,XP70-TTA TFT 256 Color Touch Screen, 10.4"
LS產電觸摸屏 PLC,XP50-TTA TFT 256 Color Touch Screen, 8.4"
LS產電觸摸屏 PLC,XP30-TTA TFT 256 Color Touch Screen, 5.7"
LS產電觸摸屏 PLC,XP30-BTA LCD Mono Touch Screen, Blue 5.7"

LS產電觸摸屏 PLC,XP31-BTE
LS產電文本顯示器 XP10BKA/DC 文本顯示微型人機界面
