樣本提供4WRKE35W6-1000L-3X/6EG24K31/A1D3M力士樂比例閥
4WRKE25W8-350L-3X/6EG24EK31/A1D3M力士樂比例閥
特點: 5位4通先導控制二級比例方向閥
用途: 用于控制液流的規格大小和方向
價格國內具有優勢,貨期穩定（22-26周）
材料訂貨號SN是R900245067
功能類似PARKER系列D81FH（D91FH）
帶***控制的線性控制曲線
內置集成電子元件(放大器)
電壓控制值/實際值-10V到10V
帶電氣位置反饋
4WRKE25W8-350L-3X/6EG24EK31/A1D3M公稱規格尺寸25mm
額定流量350L/min
大流量870l/min
大工作壓力35MPA（350 bar）
規格型號自帶減壓閥ZDR 6 DP0-4X/40YM-W80
主級由閉環位置控制
閥芯位置獨立于較大流量的液動力
內部先導供油，外部先導泄油
板式連接結構
安裝面按ISO 4401
組件系列3X=30、31、32、33……39, 安裝和連接尺寸一致
R961004762 REGULATOR4WRKE16.-33/A1*BG
R901179163 4WRKE25E1-220L-3X/6EG24K31/A1D3M-280
R901153191 4WRKE25W6-220L-3X/6EG24TK31/A1D3M
R901146772 4WRKE10W8-100L-3X/6EG24EK31/F1D3M
R901144327 4WRKE10W8-100L-3X/6EG24K31/F1D3M
R901136533 4WRKE35W6-1000L-3X/6EG24K31/A1D3M
R901121866 4WRKE10E25L-3X/6EG24EK31/A1D3M-280
R901120323 4WRKE10R3-50L-3X/6EG24ETK31/F1D3V
R901119151 4WRKE10E1-50L-3X/6EG24K31/A1D3M
R901115085 4WRKE27W8-500L-3X/6EG24ETK31/F1D3M
R901093095 4WRKE32W8-600L-3X/6EG24EK31/F1D3M
R901092786 4WRKE27E500L-3X/6EG24K31/A1D3M
R901092067 4WRKE16W6-200P-3X/6EG24EK31/F1D3M
R901088904 4WRKE32W6-600L-3X/6EG24EK31/A1D3M
R901069770 4WRKE16E200P-3X/6EG24EK31/A1D3M
R901051257 4WRKE25W8-220L-3X/6EG24ETK31/A1D3V
R901051256 4WRKE16W8-125L-3X/6EG24ETK31/A1D3V
R901049852 4WRKE16E3-125L-3X/6EG24K31/F1D3V
R901041512 4WRKE27W6-500L-3X/6EG24EK31/A1D3M
R901033473 4WRKE32E600L-3X/6EG24EK31/A1D3M
R901030855 4WRKE25E350L-3X/6EG24K31/A1D3M-280
R901030854 4WRKE16E125L-3X/6EG24K31/A1D3M-280
R901024647 4WRKE35E1000L-3X/6EG24K31/A1D3M-280
R901022395 4WRKE25W6-220L-3X/6EG24K31/A1D3M
R901017928 4WRKE16W6-200P-3X/6EG24EK31/A1D3M
R900704916 4WRKE16E200L-3X/6EG24ETK31/A1D3M
R900702633 4WRKE10W6-50L-3X/6EG24ETK31/A5D3M
R900702614 4WRKE10E100L-3X/6EG24EK31/A5D3M
R900702613 4WRKE16E200L-3X/6EG24EK31/A5D3M
R900702610 4WRKE10W6-50L-3X/6EG24EK31/A5D3M
R900702609 4WRKE10E50L-3X/6EG24EK31/A5D3M
R900702241 4WRKE16E200L-3X/6EG24K31/A5D3M
R900701446 4WRKE32W6-600L-3X/6EG24TK31/A1D3M
R900701445 4WRKE16W6-200L-3X/6EG24TK31/A1D3M
R900700594 4WRKE10E100L-3X/6EG24TK31/A5D3M-574
R900700305 4WRKE25E3-350P-3X/6EG24EK31/A1D3M
R900641220 KOLBEN4WRKE25W000-20/-435
R900631248 GEHAEUSE4WRKE10.-10/-REGLER
R900631247 DECKEL4WRKE10.-10/-REGLER
R900617303 4WRKE16W6-125L-3X/6EG24K31/A1D3M
R900616821 4WRKE27W6-500L-3X/6EG24K31/A5D3M
R900616658 4WRKE10W8-50L-3X/6EG24ETK31/A1D3M
R901138077 4WRKE16W6-200L-3X/6EG24ETK31/C1D3V
R901136533 4WRKE35W6-1000L-3X/6EG24K31/A1D3M
R901135910 4WRKE35E1000L-3X/6EG24TK31/A1D3M
R901133523 4WRKE16R3-125L-3X/6EG24K31/A1D3M
R901133144 4WRKE27E500L-3X/6EG24K31/F1D3M
R901133143 4WRKE25E220L-3X/6EG24K31/F1D3M
R901132750 4WRKE32W2-600L-3X/6EG24K31/A5D3M
R901131241 4WRKE10W6-25L-3X/6EG24K31/A1D3M
R901130165 4WRKE27E500L-3X/6EG24K31/C1D3M
R901130162 4WRKE16E125L-3X/6EG24K31/C1D3M
R901129810 4WRKE16W6-125L-3X/6EG24K31/F1D3V
R901129320 4WRKE10E50L-3X/6EG24K31/A5D3M-259
R901128913 4WRKE16R200P-3X/6EG24K31/A1D3M
R901127413 4WRKE35W8-1000L-3X/6EG24EK31/F1D3M
R901127306 4WRKE16R125L-3X/6EG24EK31/A1D3M
R901126339 4WRKE27W8-500L-3X/6EG24ETK31/A5D3M
R901125661 4WRKE10E100L-3X/6EG24EK31/F1D3M
R901125572 4WRKE25W6-220L-3X/6EG24ETK31/F1D3M
R901125229 4WRKE32E400L-3X/6EG24EK31/A1D3M
R901125163 4WRKE25R350L-3X/6EG24EK31/A1D3M
R901124993 4WRKE25W8-350L-3X/6EG24TK31/F1D3M
R901124444 4WRKE32E1-600L-3X/6EG24EK31/C1D3M
R901124442 4WRKE32W6-400L-3X/6EG24ETK31/F1D3M
R901124438 4WRKE32E600L-3X/6EG24ETK31/A1D3V
R901124051 4WRKE35EA1000L-3X/6EG24EK31/A1D3M
R901123813 4WRKE16E200L-3X/6EG24K31/A1D3V
R901123669 4WRKE25EA350L-3X/6EG24K31/A1D3M
R901123577 4WRKE25E3-350L-3X/6EG24TK31A1D3M
R901123279 4WRKE10W6-100L-3X/6EG24K31/A1D3V
R901122589 4WRKE32W6-400L-3X/6EG24EK31/F1D3M
R901121949 4WRKE32W8-400L-3X/6EG24EK31/F1D3M
R901121948 4WRKE25W6-350L-3X/6EG24EK31/F1D3M
R901121866 4WRKE10E25L-3X/6EG24EK31/A1D3M-280
R901121491 4WRKE16W6-125P-3X/6EG24K31/A1D3M
R901121445 4WRKE16E3-125L-3X/6EG24ETK31/A1D3M
R901120773 4WRKE10R3-50L-3X/6EG24ETK31/F1D3M
R901120323 4WRKE10R3-50L-3X/6EG24ETK31/F1D3V
R901119949 4WRKE16W6-200L-3X/6EG24EK31/A1D3V
R901119343 4WRKE32E400L-3X/6EG24K31/A5D3M-280
R901119151 4WRKE10E1-50L-3X/6EG24K31/A1D3M
R901118414 4WRKE25W6-350L-3X/6EG24K31/A5D3M-871
R901117336 4WRKE32E1-600L-3X/6EG24EK31/A1D3M
R901117295 4WRKE32W6-400L-3X/6EG24K31/F1D3M
R901115913 4WRKE25W8-350P-3X/6EG24TK31/A1D3M
R901115172 4WRKE16E200S-3X/6EG24ETK31/A1D3M
R901115085 4WRKE27W8-500L-3X/6EG24ETK31/F1D3M
R901114885 4WRKE25E350L-3X/6EG24K31/F1D3V
R901112725 4WRKE16EA125L-3X/6EG24EK31/A1D3M
R901111135 4WRKE25E1-350P-3X/6EG24K31/F1D3M
R901109715 4WRKE25R3-220L-3X/6EG24ETK31/A5D3M
R901109412 4WRKE27W500P-3X/6EG24EK31/A1D3M-877
R901108789 4WRKE25W6-220L-3X/6EG24K31/A1D3V
R901108788 4WRKE16W6-200L-3X/6EG24K31/A1D3V
R901108088 4WRKE25E350P-3X/6EG24EK31/A5D3M
R901107963 4WRKE25W6-350L-3X/6EG24EK31/A5D3V
R901107424 4WRKE32W8-400L-3X/6EG24EK31/A1D3M
R901105587 4WRKE16W6-125L-3X/6EG24ETK31/A5D3V
R901105489 4WRKE25R3-000S-3X/6EG24K31/A5D3M-805
R901105145 4WRKE16W8-200L-3X/6EG24EK31/A5D3WC15M
R901104963 4WRKE25R3-350L-3X/6EG24ETK31/A1D3M
R901103694 4WRKE25R5-220L-3X/6EG24EK31/A1D3M
R901102982 4WRKE32E1-600L-3X/6EG24K31/A1D3M
R901102529 4WRKE35E1000L-3X/6EG24K31/A1D3V
R901101371 4WRKE16W8-200L-3X/6EG24K31/A5D3M-280
