90° Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO/Exd/Exe
The 90° swivel adaptor (types FP, FQ, FR) has been designed to allow a full 360° choice of cable entry/exit positions. This enables the installer to run the cable in any direction which greatly improves ease of installation in confined or difficult situations. The cable entry/exit can be aligned without the over or under torque compromise imposed by the direction of the cable. The in-line type (types FA, FC, FD) allows independent connection at both ends.
Certifications and compliances
Code of protection categories ATEX: I M2, Ex d IMb, Ex e I Mb, (not aluminium) or IIGd Ex d IIC Gb, Ex e IIC Gb, Ex tb IIIC Db
IECEx: Ex d Ex e IIC Gb, Ex d Ex e IM (not aluminium), Ex tb IIIC Db, IP 6X
INMETRO: Ex d IIC Gb, Ex e IIC Gb, Ex d I Mb, Ex e Mb, Ex tb IIIC Db IP6X
Compliance standards ATEX: EN 60079-0, EN60079-1, EN 60079-7, EN 60079-31
INMETRO: ABNT NBR IEC 60079-0, ABNT NBR IEC 60079-1, ABNT NBR IEC 60079-7, ABNT NBR IEC 60079-31 IECEx: IEC 60079-0, IEC 60079-1, IEC 60079-7, IEC 60079-31
Certificate details ATEX: Sira 10ATEX1056U, ITS16ATEX101337U IECEx: IECEx SIR 10.0025U, IECEx ITS16.0010U INMETRO: NCC 12.0764X
Temperature Temperature range: -20°C to +60°C Exd, -50°C to +200°C Exe Ingress protection (IP): Independently tested to IP66 / IP68 when fitted in accordance to manufacturer’s instructions.
| FPA1212YXN |
Raxton Adapt |
M20 x M20 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1213Y |
Raxton Adapt |
M20 x M20 90 Degree Swivel Adaptor Male to Female Brass Nickel Plated ATEX/IECEx/INMETRO Exd/Exe |
| FPA1213YXN |
Raxton Adapt |
M20 x M25 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1242Y |
Raxton Adapt |
M20 x M25 90 Degree Swivel Adaptor Male to Female Brass Nickel Plated ATEX/IECEx/INMETRO Exd/Exe |
| FPA1242YXN |
Raxton Adapt |
M20 x 1/2" NPT 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1312Y |
Raxton Adapt |
M20 x 1/2" NPT 90 Degree Swivel Adaptor Male to Female Brass Nickel Plated ATEX/IECEx/INMETRO Exd/Exe |
| FPA1312YXN |
Raxton Adapt |
M25 x M20 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1313Y |
Raxton Adapt |
M25 x M20 90 Degree Swivel Adaptor Male to Female Brass Nickel Plated ATEX/IECEx/INMETRO Exd/Exe |
| FPA1313YXN |
Raxton Adapt |
M25 x M25 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1343Y |
Raxton Adapt |
M25 x M25 90 Degree Swivel Adaptor Male to Female Brass Nickel Plated ATEX/IECEx/INMETRO Exd/Exe |
| FPA1343YXN |
Raxton Adapt |
M25 x 3/4" NPT 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1413Y |
Raxton Adapt |
M25 x 3/4" NPT 90 Degree Swivel Adaptor Male to Female Brass Nickel Plated ATEX/IECEx/INMETRO Exd/Exe |
| FPA1413YXN |
Raxton Adapt |
M32 x M25 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1414Y |
Raxton Adapt |
M32 x M25 90 Degree Swivel Adaptor Male to Female Brass Nickel Plated ATEX/IECEx/INMETRO Exd/Exe |
| FPA1414YXN |
Raxton Adapt |
M32 x M32 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1444Y |
Raxton Adapt |
M32 x M32 90 Degree Swivel Adaptor Male to Female Brass Nickel Plated ATEX/IECEx/INMETRO Exd/Exe |
| FPA1514Y |
Raxton Adapt |
M32 x 1" NPT 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1515Y |
Raxton Adapt |
M40 x M32 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1515YXN |
Raxton Adapt |
M40 x M40 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1545Y |
Raxton Adapt |
M40 x M40 90 Degree Swivel Adaptor Male to Female Brass Nickel Plated ATEX/IECEx/INMETRO Exd/Exe |
| FPA1615Y |
Raxton Adapt |
M40 x 1 1/4" NPT 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1616Y |
Raxton Adapt |
M50 x M40 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1616YXN |
Raxton Adapt |
M50 x M50 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1646Y |
Raxton Adapt |
M50 x M50 90 Degree Swivel Adaptor Male to Female Brass Nickel Plated ATEX/IECEx/INMETRO Exd/Exe |
| FPA1716Y |
Raxton Adapt |
M50 x 1 1/2" NPT 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1717Y |
Raxton Adapt |
M63 x M50 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1717YXN |
Raxton Adapt |
M63 x M63 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1747Y |
Raxton Adapt |
M63 x M63 90 Degree Swivel Adaptor Male to Female Brass Nickel Plated ATEX/IECEx/INMETRO Exd/Exe |
| FPA1817Y |
Raxton Adapt |
M63 x 2" NPT 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1818Y |
Raxton Adapt |
M75 x M63 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1818YXN |
Raxton Adapt |
M75 x M75 90 Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO Exd/Exe |
| FPA1848Y |
Raxton Adapt |
M75 x M75 90 Degree Swivel Adaptor Male to Female Brass Nickel Plated ATEX/IECEx/INMETRO Exd/Exe |
